Description
xMille power amplifiers are born to fully enhance the outstanding performance of the Mille speakers. The new ADC (ADVANCED D-CLASS TECHNOLOGY) ensures pure listening pleasure while keeping a compact size with unmatched power efficiency. The heat sink, engineered with double technology, extrusion and aluminium die-casting, enables the Mille Power amplifiers to work constantly at full power without ever overheating, further maximizing thermal efficiency. The ultra-versatile Hertzaudio car amplifier ML Power 5 (100 W x 4 + 550 W 2 Ω) provides the ability to drive a Mille system including the subwoofer. The HRC BM (Hertz Remote Control Bass Management), low frequencies level remote control, is optional.
General Specs
- Channels 5 - 3
- Power supply voltage: 11÷15 VDC
- Idling current: 3 A
- Idling current when off: 0.04 mA
- Consumption @ 1Ω, 14.4 VDC
- (Max Musical Power) 50 A
- Distorsion - THD (100 Hz @ 4Ω): 0.08 %
- Bandwidth A & B Ch (-3 dB): 5 ÷ 50k Hz
- Bandwidth C Ch (-3 dB): 5 ÷ 500 Hz
- S/N Ratio A & B Ch (A weighted @ 1 V) 100 dB
- S/N Ratio C Ch (A weighted @ 1 V): 106 dB
- Damping factor A & B Ch (100 Hz @ 4Ω): 50
- Damping factor C Ch (100 Hz @ 4Ω): 90
- Pre-In sensitivity: 0.2 ÷ 5 V RMS
- Pre-In impedance: 15 kΩ
- Speaker-In sensitivity: 0.8 ÷ 20 V RMS
- Speaker-In impedance: 470 Ω
- Load impedance:
- 5 Ch 4 x 2Ω + 1 x 2Ω
- 3 Ch 2 x 4Ω + 1 x 2ΩRemote In: 4 ÷ 15 VDC - 1 mA
- ART™: Automatic Remote Turn-On/Off with Speaker-In
- Fuse: 2 x 40 A
- Max size (mm/inches): 170 x 349 x 46.70 / 6.69 x 13.74 x 1.84
- Adjustable Crossovers
Output Power
- CEA 2006-A RATINGS
- RMS Power (4 Ω, ≤ 1 % THD+N, 14.4 V):
- 60 W x 4 Ch + 310 W x 1 Ch
- S/N Ratio (ref. 1 W output):
- 60 W Channel: 80 dBA
- 310 W Channel: 84 dBA
- OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%:
- 5 Ch - 70 W x 4 + 380 W x 1 (4Ω)
- 5 Ch - 100 W x 4 + 550 W x 1 (2Ω)
- 3 Ch - 200 W x 2 (4Ω) + 380 W x 1 (4Ω)
- 3 Ch - 200 W x 2 (4Ω) + 550 W x 1 (2Ω)
- Total Power RMS - 950 W
INPUTS / FILTERS
- Inputs: Pre IN / Speaker IN
- A Ch filters: Full / Hi-Pass / Band-Pass 40 ÷ 150 Hz (HI) 80 ÷ 3.3k Hz (LO) @ 12 dB/Oct.
- B Ch filters: Full / Hi-Pass 80 ÷ 3.3k Hz @ 12 dB/Oct.
- C Ch filters: Lo-Pass 50 ÷ 500 Hz @ 24 dB/Oct.
- Remote SUB volume: (-50 ÷ 6) dB
