Description
xAudio excellence and system design flexibility from this compact 2 X 80watts RMS into 4 ohms amplifier. Universal Speaker Simulator and on-board filtering offer a comprehensive set of controls for precise system design and performance.
Specification
- Channels: 2 - 1
- Amp class: AB
- Nominal power supply voltage (fuse): 11 - 15 VDC (2 x 20 A)
- Operating power supply voltage: 6.5 - 16.5 VDC
- Idling current: 0.65 A
- Standby current draw: 5 uA
- Consumption, MIN load impedance (Max Musical Power): 15 A
- Remote IN: 4 - 15 VDC (1.5 mA)
- ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only): 1.5 VDC
- Efficiency: 60%
- Distortion - THD @ 100 Hz, 70% Rated Power: 0.01%
- Damping factor @ 1 kHz, 1W: 130
- Bandwidth @ -3 dB: 10Hz - 45kHz
- S/N ratio (A-weighted @ 1 V Input): 100 dBA
- Minimum load impedance
- @ 2 Ch: 2 Ω
- @ 1 Ch: 4 Ω
- Adjustable Crossovers yes
- Output Power
Output power (RMS) @ 1% THD:
- 2Ch @ 4Ω 80 W x 2
- 2Ch @ 2Ω 110 W x 2
- 1Ch @ 4Ω 220 W x 1
Output Power (RMS) @ 14.4 VDC, THD 10%:
- 2Ch @ 4Ω 95 W x 2
- 2Ch @ 2Ω 130 W x 2
- 1Ch @ 4Ω 260 W x 1
- Total Power 520 W
INPUTS / FILTERS
- Inputs Pre-In / Speaker-In
- Pre Out Full Range
- Pre-In sensitivity: 0.32 - 8 VRMS
- Speaker-In sensitivity: 1.6 - 40 VRMS
- Hi-Pass Full / 50-4000Hz 12dB/Oct.
- Lo-Pass Full / 50-4000Hz 12dB/Oct.
- Bass Boost 50Hz: 0 - 9 dB
