Description
x- AMPLIFIER TECH DATA
- Channels - 12
- Class - D-Class
- Efficiency - 80%
- Power supply voltage / fuse - 11 ÷ 15 VDC / 2 x 30A
- Operating power supply voltage - 6.5 ÷ 17.5 VDC
- Idling current - 1.68 A
- Standby Current Draw - 1.7 mA
- Consumption @ 14.4 VDC, 2Ω, Max Musical Power - 45 A
- Remote IN - 4 ÷15 VDC (1 mA)
- Remote OUT - 6.5 ÷15 VDC (150 mA)
- ART - Automatic Remote Turn on/ off from OUTPUT BTL speakers - 1.5 VDC
- Efficiency Rated Power - 80%
- AMPLIFIER STAGE
- Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power - 0.03%
- Bandwidth @ -1.5 dB - 10 Hz ÷ 42 kHz
- Damping factor @ 1 kHz, 4Ω, 2 VRMS - 80
- S/N ratio (A weighted @ 1 V Input) Master Input - 98 dBA
- S/N ratio (A weighted @ 1 V Input) Optical Input - 105
- Total Power RMS - 1080 W
- Minimum load impedance - 12Ch: 2Ω | 6Ch – (Bridge 1/2; 3/4; 5/6; 7/8; 9/10; 11/12): 4Ω
- Output Continuous Power (RMS) @14.4 VDC, 1% THD
- 12 Ch @ 4Ω: 60 W x 12
- 12 Ch @ 2Ω: 90 W x 12
- 6 Ch (Bridge 1/2; 3/4; 5/6; 7/8; 9/10; 11/12) @ 4Ω: 180 W x 6
- Adjustable Crossover - Yes
- CEA SPECIFICATIONS
- Output power @ 4Ω, 1% THD+N, 14.4 V - 45 W
- SN ratio (ref. 1W output) - 75.5 dB
- INPUTS / OUTPUTS
- Pre-In Inputs - 0.6 ÷ 6 VRMS (15 kΩ Imp.)
- Digital Input - Yes
- Pre Outputs - 2
- Hi Level Inputs - 8
- Low Level Inputs - 8
- Speaker-In Inputs - 2.2 ÷ 22 VRMS (5 Ω Imp.)
- Digital IN - 1 x Optical S/PDIF; Max 192 kHz / 24 bit + 1 x Optical/Coaxial S/PDIF with optional F2O card
- Sub Out (RCA Pre Out) - 5V RMS
- DIGITAL SIGNAL PROCESSOR
- Audio DSP Converter - Analog Devices ADAU1467 automotive qualified audio processor. Processing @ 96 kHz.Analog Devices 3 x ADAU1978 (4ch) and ADAU1966A (16ch) A/D
- and D/A converters (24 bit/192 kHz) providing very high level performance
- Filter type - Full / High-Pass / Low-Pass / Band-Pass
- Filter mode and slope - Linkwitz-Riley @ 12/24/36/48 dB/Oct.
- Butterworth @ 6/12/18/24/30/36/42/48 dB/Oct.
- Bessel @ 6/12/18/24/30/36/42/48 dB/Oct.
- Chebyshev @ 6/12/18/24/30/36/42/48 dB/Oct.
- QLP @ 6 dB/Oct.
- Crossover frequency - 20 Hz ÷ 20 kHz
- Phase control - 0° / 180°, All-Pass filters
- Analog Input Equalizer (20 ÷ 20k Hz) - 12 Biquad + Delay
- Output Equalizer - Parametric/Graphic Biquad: 15 poles, 20 Hz ÷ 20 kHz
- Time Alignment Distance - 0 ÷ 510 cm / 0 ÷ 200.8 inches
- Time Alignment Delay - 0 ÷ 15 ms
- Input Output Real Time Audio Monitor - RTA
- CONTROL CONNECTIONS
- DRC Port - Input for DRC AC remote control (Optional)
- ADC Port - Manage other Audison devices that support this standard
- 1 Wire - Customizable functions (+ 12 V activated)
- 2 Wire - Customizable functions (+ 12 V activated)
- GENERAL REQUIREMENTS
- PC connections - Micro USB 1.1 / 2.0 / 3.0 Compatible
- Software/PC requirements - Windows 10, Windows 11 (min. res. 1024 x 768
- Ambient operating temperature range - 0 °C to 55 °C (32 °F to 131 °F)
- Size - 240 x 47 x 156 / 9.44 x 1.85 x 6.14
- Weight - 2.04 kg
