Description
xF companion amplifiers are designed to add powerful amplifier channels to AF bit processor amplifiers. A plug-and-play signal input harness is included to make connection to AF bit amplifiers straightforward.
AF companion amplifiers are also perfect for use with systems controlled and managed by a standalone bit processor, such as a bit One HD Virtuoso.
AF companions have a “straight wire” architecture, without analog preamp functions such as crossover filtering, and are intended for use with external processors. AF M4D boasts four high-fidelity amplified channels 90W x 4 @4Ω*, 150W x 4 @2Ω* with the audiophile sound of the latest generation Audison D-Class technology.
Higher switching frequencies, steeper filtering, and higher-tolerance components deliver sound above and beyond the expectation of Class D – in an amazingly compact package!
The audio band is extended up to 40 kHz earning the coveted High-Resolution certification. Bridging channel pairs results in 300W x 2 @4Ω*, guaranteeing flexible and powerful performance. *Output Continuous Power (RMS) @14.4 VDC, 1% THD, all channels driven.
AMPLIFIER TECH DATA
- Channels 4
- Class D-Class
- Efficiency 84%
- Hi Level Input
- Low Level Input
- Power supply voltage / fuse 11 ÷ 15 VDC
- Operating power supply voltage 6.5 ÷ 17.5 VDC
- Idling current 0.004 A
- Idling current when off 0.6 mA
- Consumption @ 14.4 VDC, 2Ω, Max Musical Power 25 A
- Remote OUT 6.5 ÷15 VDC (150 mA)
- Remote IN 4 ÷15 VDC (1 mA)
- ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 1.5 VDC
AMPLIFIER STAGE
- Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power 0,03%
- Bandwidth A (-3 dB, 2 VRMS, 4 Ω): 10Hz ÷ 40kHz
- S/N ratio A (A weighted @ 1 V): 102 dBA
- Damping factor A (1 kHz, 4Ω, 2 VRMS): 95
- Input sensitivity Pre-In 0.6 ÷ 6 VRMS
- Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
- Total Power RMS 600 W
- Minimum load impedance 2Ω:
- Output Power (RMS) @14.4 VDC, 1% THD
- 4Ch @ 4Ω: 90 W x 4
- 4Ch @ 2Ω: 150 W x 4
- 2Ch (bridge) @ 4Ω: 300 W x 2
CEA SPECIFICATIONS
- Output power @ 4Ω, 1% THD+N, 14.4 V 90 W x 4
- SN ratio (ref. 1W output) 81 dBA
- INPUTS
- Input Type Pre-In / Speaker-In
- Remote Sub Volume ±12 dB
- OTHER Fuse 1 x 30 A
- Weight 1.49 kg
Dimensions
- Dimension A 200 mm
- Dimension B 47 mm
- Dimension C 134 mm
